| 设备型号 | 加工宽度范围 (mm) |
工作厚度 (mm) |
输送带速度 |
滚刀驱动电机功率 |
磨头升降电机功率 |
单头耗水量 (L/min) |
单台机外形尺寸 (L×W×H) (mm) |
总 重 |
|---|---|---|---|---|---|---|---|---|
|
GD600/6 |
300-600 |
5-20 |
6-28 |
11 |
0.37 |
80 |
7560×2520x×1825 | 11200 |
|
GD600/8 |
300-600 |
5-20 |
6-28 |
11 |
0.37 |
80 |
9140×2520×1825 | 14100 |
|
GD600/10 |
300-600 |
5-20 |
6-28 |
11 |
0.37 |
80 |
11260×2520×1825 | 17850 |
|
GD600/12 |
300-600 |
5-20 |
6-28 |
11 |
0.37 |
80 |
13110×2520×1825 | 21100 |
|
GD800/6 |
400-800 |
5-20 |
6-28 |
15 |
0.37 |
85 |
7560×2720×1825 | 12320 |
| GD800/8 | 400-800 | 5-20 | 6-28 | 15 | 0.37 | 85 | 9140×2720×1825 | 15510 |
| GD800/10 | 400-800 | 5-20 | 6-28 | 15 | 0.37 | 85 | 11260×2720×1825 | 19635 |
| GD800/12 | 400-800 | 5-20 | 6-28 | 15 | 0.37 | 85 | 13110×2720×1825 | 23210 |
| GD1000/6 | 400-1000 | 5-20 | 6-28 | 18.5 | 0.37 | 90 | 7560×2920×1825 | 13650 |
| GD1000/8 | 400-1000 | 5-20 | 6-28 | 18.5 | 0.37 | 90 | 9140×2920×1825 | 14000 |
| GD1000/10 | 400-1000 | 5-20 | 6-28 | 18.5 | 0.37 | 90 | 11260×2920×1825 | 18000 |
| GD1000/12 | 400-1000 | 5-20 | 6-28 | 18.5 | 0.37 | 90 | 13110×2920×1825 | 21650 |
| GD1200/6 | 500-1200 | 5-20 | 6-28 | 22 | 0.37 | 95 | 7560×3120×1825 | 15200 |
| GD1200/8 | 500-1200 | 5-20 | 6-28 | 22 | 0.37 | 95 | 9140×3120×1825 | 18000 |
| GD1200/10 | 500-1200 | 5-20 | 6-28 | 22 | 0.37 | 95 | 11260×3120×1825 | 19900 |
| GD1200/12 | 500-1200 | 5-20 | 6-28 | 22 | 0.37 | 95 | 13110×3120×1825 | 23900 |
